5U Rack Mount 48V 150Ah Lithium LiFePO4 Batteries For Communication Equipment

Place of Origin CHINA
Brand Name EA ENERGY
Certification CE MSDS UN38.3
Model Number 48V 100Ah 150Ah
Minimum Order Quantity 1PCS
Price Negotiable
Packaging Details 60x42x27cm 1pcs / carton GW:55kg
Delivery Time 1-5 Work days
Payment Terms T/T, Western Union, MoneyGram, T/T, D/P
Supply Ability 100000pcs Per Day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Voltage 48V Diameter 538x398x230mm
Model 48100 48150 Cell Type 3.2V Prismatic Battery Cells
Capacity 100Ah 150Ah Impedance <100mΩ
Cycle Life >4000 Cycles Standard Charge Current Constant Current 1C
Certifications CE /UL/UN38.3/ MSDS Standard Discharge Current Constant Current 1C
High Light

5U Rack Lithium LiFePO4 Batteries

,

150Ah Lithium LiFePO4 Batteries

,

Prismatic LiFePO4 Battery Pack

Leave a Message
Product Description

5U Rack Mount 48V 100Ah 150Ah Lithium LiFePO4 Battery Pack For Communication Equipment , Home Solar System



Customization Lithium Ion Battery 48V 100Ah LiFePO4 for Solar Energy Storage Systems , access network equipment, far-end telephone exchange Communication Equipment , Home Solar System



48V 100Ah Lithium LiFePO4 Battery Pack details :



1. Diameter*Height : 480x222x442cm (Lithium prismatic LiFePO4  15S1P )

2. Nominal Voltage : 48V

3. Nominal Capacity : 100Ah

4. Cycle life : 5000 cycles

5. Standard charging ways : CC / CV

6. Li-ion / Lithium Ion rechargeable LiFePO4 battery cell

7. CE , UL ,UN38.3 , MSDS compliant





48V 100Ah Lithium LiFePO4 Battery Pack Description :



EA 48150-5U 48V Lithium Ion Battery 150Ah TELECOMMUNICATIONS BATTERIES



The EA 48150 5U is a one hundred fiifty ampere hour (150AH) battery that has a market leading low profile that measures only 8.74 inches of vertical rack height (5U) in the slender 19" wide mounting. The total weight is only 119.5 pounds making it easy to install with an industry first flexible mounting system. The mounting battery can be mounted in a 19" or 23" rack with multiple position mounting strip to vary the front location to match your cabinet.



EA 48150 5U is a powerful 48V LiFePO4 battery model which has been specifically designed to provide battery backup for rack or cabinet telecom sites. Its modular design enables parallel installation to meet the needs of longer backup times. Lithium iron phosphate ( LiFePO4) chemistry is one of the safest lithium batteries sold in the stationary market.



EA 48150-5U Lithium Ion Battery 150Ah APPLICATIONS
Wireless and RODF Hut Back-Up Power
Wireless and RODF Repeater Back-Up Power
Customer Premise / PBX
48V Broadband
Microwave Repeater
Fiber Optic Regen Sites
FTTB & LAN/WIFI Connection Power
Street and Highway Monitoring and Surveillance




Lithium iron phosphate (LiFePO4) is used as positive material, which offers extended cycle life and one of the safest chemistries
EA LFP battery will provide 4000 – 9000 cycles depending on depth of discharge and ten times the cycles of traditional lead acid
Modules can be paralleled to provide additional current for longer backup times
Embedded BMS offers voltage, current, temperature protection and alarm functions, and the BMS can communicate with other devices by Modbus protocol.



EA 48150-5U DESIGNED IN SAFE OPERATION
IEC 60950 - Information technology equipment – Safety
IEC 62133 Part 2 - Safety requirements for portable sealed secondary lithium cells, and for batteries made from them, for use in portable applications - Part 2: Lithium


UN 383 - The United Nations Recommendations on the Transport of Lithium Goods Manual of Tests and Criteria
ANSI/CAN/UL-1973 REC - UL Standard for Safety Batteries for Use in Stationary
48V Lithium Ion Battery 150Ah DESIGNED FOR PERFORMANCE


Embedded BMS unit measures voltage, current, cell surface temperature and the ambient temperature of the battery.
A secondary cut-off protection provides an extra measure of safety, and when the voltage is too low the system will cut off the support from the battery to protect the battery service life


EA 48150-5U 48V Lithium Ion Battery 150Ah TOTAL COST OF OWNERSHIP
Finally, there is a lithium solution which provides a return on your investment (ROI). The greatest advantage of lithium is the life span. The SCLFP battery will provide 4000 – 9000 cycles depending on depth of discharge while lead acid is typically done after 400 to 900 cycles. Our SCLFP provides ten times the cycles but no where near ten times the cost.





EA-48150 has been widely used in backup power of telecommunication field such as access network equipment, far-end telephone exchange, mobile telecommunication equipment, transmission facility, satellite earth station and microwave communication equipment etc.



48V 100Ah Lithium LiFePO4 Battery Pack Specifications :



Electrical
Characteristics
Nominal Voltage
51.2V
Nominal Capacity
100Ah@0.2C
Energy
5120Wh
Internal Resistance
≤35mΩ
Cycle Life
2000 Cycles @ 0.2C Charging/Discharging ,Until 70% Capacity
Self Discharge
≤3.5% per month at 25℃
Standard Charging
Max.Charging Voltage
58.4±0.2
Charging Mode
At 0℃~45℃ temperature, charged to 58.4V at a constant current of 0.2C, and then,changed continuously with constant voltage of 58.4V until the current was not more than 0.02C
Charging Current
100A
Max.Charging Current
100A
Standard Discharging
Discharging Current
100A
Max. Continuous Current
100A
Max.Pulse Current
110A(10S) Can be set up
Discharging Cut-off Voltage
40.0
Operating Condition
Charge Temperature
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
Discharge Temperature
-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
Storage Temperature
0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
Water Dust Resistance
IP54
Structure
Cell & Format
GSP34135214F (16S1P)
Casing
Metal
Max.Dimension (L*W*H)
538*398*230mm(5U)
Weight
Approx. 55Kg
Communication Interface
RS485 (8P8C)
Display
LCD


48V 100Ah Lithium LiFePO4 Battery Pack Products Details :



5U Rack Mount 48V 150Ah Lithium LiFePO4 Batteries For Communication Equipment 05U Rack Mount 48V 150Ah Lithium LiFePO4 Batteries For Communication Equipment 1







48V 100Ah Lithium LiFePO4 Battery Pack Applications :



EA-48100 has been widely used in backup power of telecommunication field such as access network equipment, far-end telephone exchange, mobile telecommunication equipment, transmission facility, satellite earth station and microwave communication equipment etc.
