5000 Cycles 3.2V 3400mAh 9.2Wh Li Iron Battery 26650 LiFePO4 Cell

Place of Origin CHINA
Brand Name EA ENERGY
Certification CE MSDS UN38.3
Model Number 26650 3400mAh
Minimum Order Quantity 1PCS
Price Negotiable
Packaging Details 27*27*15cm 200pcs / carton GW:14kg
Delivery Time 1-5 Work days
Payment Terms T/T, Western Union, MoneyGram, T/T, D/P
Supply Ability 100000pcs Per Day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Voltage 3.2V Capacity 3400mAh 9.2Wh
Diameter 26.3±0.2mm*65.3±0.2mm Cycle Life >5000 Cycles
Model 26650 Standard Discharge Current Constant Current 1C
Standard Charge Current Constant Current 1C Cell Type LiFePO4 Battery
Impedance <3mΩ Certifications CE /UL/UN38.3/ MSDS
High Light

26650 9.2Wh Li Iron Battery


3.2V 3400mAh Li Iron Battery


UN38.3 9.2Wh lifepo4 cells 26650

Leave a Message
Product Description

5000 Cycles 3.2V 3400mAh 9.2Wh Li Iron Battery 26650 LiFePO4 Cell


3.2v 3400mAh Li Iron Battery 26650 LiFePO4 Battery For Electric Bike , Solar Street Lights , Strong Light Flashlights


LiFePO4 Battery Cell Quick details:


1. Diameter*Height : 26*65mm (LiFePO4 26650 size)

2. Nominal Voltage : 3.2V

3. Nominal Capacity : 3400 mAh 9.2Wh

4. Cycle life : 5000 cycles

5. Standard charging ways : CC / CV

6. Li-ion / Lithium Ion LiFePO4 battery cell

7. CE , UL , UN38.3 , MSDS compliant


26650 LiFePO4 Battery Description:


EA Energy LiFePO4 battery use Automotive Grade LiFePO4 Cells with higher energy density, more stable performance and greater power.


The battery uses imported original big brand ion batteries, with a small internal resistance, big capacity, cycle times and more, no memory effect, etc; internal circuit for multiple protection design, can prevent over charge, over discharge, over current; production process quality inspection and monitoring the use of computers to ensure superior battery performance.


26650 batteries, also known as 1/3 AAA batteries, are rechargeable lithium-ion cells. A 26650 battery is able to generate high voltages while also being safe and efficient, making them ideal batteries for high-powered LED flashlights. Available as both protected and unprotected, 26650 batteries are the perfect companion for high drain devices and are produced by some of the most trusted lithium-ion battery companies.


the voltage is stable, far superior to ternary polymer batteries and lead acid batteries.


90% of the energy of the iron phosphate battery is concentrated in a small area of 3-3.2v, and the discharge characteristics are very stable.
lithium iron phosphate is strictly Safety tests do


We can also customize any size and function you need.Such as 12V/24V/36v/48v/60V/72v 20AH, 50AH,100h, 120ah, 150ah,200ah, 300ah, 400ah, 800ah etc..


LiFePO4 Battery Cell Specifications :


NO Items Specification Remarks
1 Nominal Capacity 3400mAh 0.2C 5A Discharge
0.2C 5A Discharge
2 Nominal Voltage/shipping voltage 3.2V/3.15-3.25V Voltage
3 Discharge Cut-off Voltage 2.0V 0.2C 5A Discharge
0.2C 5A Discharge
4 Charge Limited Voltage 3.65±0.03V 0℃~45℃
5 Standard Charge Current 1C A 0℃~45℃
6 Standard Discharge Current 1C A -20℃~ +60℃
7 Rapid Charge Current 1C A 10℃~45℃
8 Rapid Discharge Current 1C A -20℃~ +60℃
9 Max. Charge Current 3C A
Max Pulse Current 3C
10 Internal Impedance ≤5mΩ AC 1kHz condition
At AC 1kHz
11 Weight About 80.0g Weight 80±2g
12 Storage Temperature Range ≤1 month -20~ 45℃ Factory Voltage 3.3~3.45V
≤3 months 0℃~ +30℃ Ex-factory Voltage3.3~3.45V
≤12 months 20±5℃


LiFePO4 Battery Cell Other 26650 cells :



Part No


Nominal Voltage


Rated Capacity


Internal Resistance


Discharge Rate




Diameter Height
EA-LFP26650-3.2V-2500mAh 3.2V 2500mAh <10 m Ω 20C 26.3±0.1 65.2±0.2 87
EA-LFP26650-3.2V-3000mAh 3.2V 3000mAh <10 m Ω 10C 26.3±0.1 65.2±0.2 85
EA-LFP26650-3.2V-3200mAh 3.2V 3200mAh <25 m Ω 3C 26.3±0.1 65.2±0.2 85
EA-LFP26650-3.2V-3300mAh 3.2V 3300mAh <25 m Ω 3C 26.3±0.1 65.2±0.2 85
EA-LFP26650-3.2V-3400mAh 3.2V 3400mAh <25 m Ω 3C 26.3±0.1 65.2±0.2 85
EA-LFP26650-3.2V-3600mAh 3.2V 3600mAh <25 m Ω 3C 26.3±0.1 65.2±0.2 85
EA-LFP26650-3.2V-3800mAh 3.2V 3800mAh <25 m Ω 3C 26.3±0.1 65.2±0.2 87
EA-LFP26650-3.2V-4000mAh 3.2V 4000mAh <25 m Ω 3C 26.3±0.1 65.2±0.2 88

LiFePO4 Battery Cell Products Details :


5000 Cycles 3.2V 3400mAh 9.2Wh Li Iron Battery 26650 LiFePO4 Cell 0


LiFePO4 Battery Cell Applications:


26650 Battery cells Perfect for Wireless camera, surveillance cameras, wireless infrared detector, car LCD TV, portable DVD, personal treatment system, PDA personal data assistant, personal communications systems, walkie-talkies, digital cameras, camcorders, video cameras, Bluetooth devices, CD players, MD players, MP3 players, smart cards, aviation model LED lights and other fields can be used with LiFePO4 batteries.

5000 Cycles 3.2V 3400mAh 9.2Wh Li Iron Battery 26650 LiFePO4 Cell 1
