12V 5Ah 4S1P LiFePO4 Battery Packs 18650 60Wh Power Tools use

Place of Origin CHINA
Brand Name EA ENERGY
Certification CE MSDS UN38.3
Model Number 12V 5Ah
Minimum Order Quantity 1PCS
Price Negotiable
Packaging Details 40X40X70mm 1pcs / carton GW: 0.3kg
Delivery Time 1-5 Work days
Payment Terms T/T, Western Union, MoneyGram, T/T, D/P
Supply Ability 100000pcs Per Day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Model 5Ah 12V 4S1P Diameter 40X40X70mm
Cell Type 18650 LiFePO4 Battery Packs Cycle Life >5000 Cycles
Capacity 5Ah 60Wh Impedance <200mΩ
Voltage 12V Standard Discharge Current Constant Current 0.2C
Standard Charge Current Constant Current 0.2C Certifications CE /UL/UN38.3/ MSDS
High Light

12V 5Ah 4S1P LiFePO4 Battery Packs


18650 60Wh LiFePO4 Battery Packs


60Wh Power Tools Battery

Leave a Message
Product Description

12V 5Ah 4S1P LiFePO4 Battery Packs 18650 60Wh Power Tools Use


Lifepo4 Battery Pack 12V 5Ah LiFePO4 Battery Packs 60Wh Power Tools Battery


LiFePO4 Battery Packs Quick details :


1. Diameter*Height : 40X40X70mm ( Lithium Ion 18650 size 4S1P )

2. Nominal Voltage : 12V

3. Nominal Capacity : 5Ah 60Wh

4. Cycle life : 5000 cycles

5. Standard charging ways : CC / CV

6. Li-ion / Lithium Ion rechargeable LiFePO4 battery cell

7. CE , UL ,UN38.3 , MSDS compliant


Power Tools Battery Description :


12V 5AH Electric Bicycle/Ebike Battery, with 24V 20A fast Charger, 5A BMS Protection Board, T-plug/XT60 Connector and Battery Level Light,fit for 500W/350W/300W/250W/200W Bike Motor/Scooters.


LiFePO4 material is safer than LiCoO2 & LiMn2O4 for its stable structure can be kept very well under continuous charging & discharging situations.Longer than 5000 cycle life is more suitable for application use.


Deep cycle batteries, unlike cranking batteries, are designed to release power slowly. They can be drained and recharged multiple times over their lifespan. While both are important, deep cycle batteries are the ones that you depend on for most of your navigation and power. These batteries are responsible for the trolling motor and other battery powered appliances on your boat like your audio system, fish finder, and GPS.


Battery Operation And Storage
Both types of batteries have a long life when used and handled properly. Lithium-iron phosphate can handle higher temperatures as they have a nominal voltage of 3.20 to 3.30 and a 2.5-3.65V/cell operating range. These batteries have stable chemistry to where it does not experience as many negative impacts from overcharging or short circuits. It has an exceptionally long shelf-life of 350 days.


Lithium-ion batteries have a shorter shelf-life of 300 days when compared to the other. Its chemistry is a bit more unstable when experiencing higher temperatures, short circuits, and overcharging. The operating range of lithium-ion batteries is 3.0 to 4.2V /cell for lithium manganese oxide and a nominal voltage of 3.70V. Lithium cobalt oxide batteries have a nominal voltage of 3.60V and the same operating range of 3.0 to 4.2V/cell.

Thermal Runaway And Safety

Lithium iron phosphate is a safer chemistry than lithium-ion. It has exceptional thermal and chemical stability at higher temperatures and consistent power at room temperatures. It is rare for lithium iron phosphate batteries to experience thermal runaway. The battery normally stays cool as it will not explode or catch fire during overcharging or when experiencing overheating. In addition, lithium iron phosphate is not toxic. Disposal of this chemistry is easier and more cost-effective for customers.

For these reasons, EV car manufacturers look at lithium iron phosphate for electric motors. This type of battery chemistry is also used for medical devices and military devices as it is suitable for any application that requires long battery life and chemistry stability where safety is paramount.


We can also customize any size and function you need.Such as 12V/24V/36v/48v/60V/72v 20AH, 50AH,100h, 120ah, 150ah,200ah, 300ah, 400ah, 800ah etc..


LiFePO4 Battery Packs Specifications :

NO Items Specification Remarks
1 Nominal Capacity 5Ah 0.2C  Discharge
0.2C  Discharge
2 Nominal Voltage/shipping voltage 12V Voltage
3 Discharge Cut-off Voltage 10V 0.2C Discharge
0.2C Discharge
4 Charge Limited Voltage 14V 0℃~45℃
5 Standard Charge Current 5A 0℃~45℃
6 Standard Discharge Current 5A -20℃~ +60℃
7 Rapid Charge Current 0.5C 5A 10℃~45℃
8 Rapid Discharge Current 0.5C 5A -20℃~ +60℃
9 Max. Charge Current 1C 5A
Max Pulse Current 3C
10 Internal Impedance ≤10mΩ AC 1kHz condition
At AC 1kHz
11 Weight About 0.25kg Weight 250±20g
12 Storage Temperature Range ≤1 month -20~ 45℃ Factory Voltage 12~14V
≤3 months 0℃~ +30℃ Ex-factory Voltage 12~14V
≤12 months 20±5℃



LiFePO4 Battery Packs Details :


12V 5Ah 4S1P LiFePO4 Battery Packs 18650 60Wh Power Tools use 012V 5Ah 4S1P LiFePO4 Battery Packs 18650 60Wh Power Tools use 1


LiFePO4 Battery Packs Applications :


Electric Bike: Compatible with ANCHEER/VELOWAVE(Measurement is required)
Electric Scooter
Electric Motorcycle
Electric Tricycle
Solar Panels


12V 5Ah 4S1P LiFePO4 Battery Packs 18650 60Wh Power Tools use 2
