18650 48V 20AH Lithium Battery For Motor Electric Bicycle Bike Scooter

Place of Origin CHINA
Brand Name EA ENERGY
Certification CE MSDS UN38.3
Model Number 48V 20Ah
Minimum Order Quantity 1PCS
Price Negotiable
Packaging Details 29.5*9*7.3cm 1pcs / carton GW: 6kg
Delivery Time 1-5 Work days
Payment Terms T/T, Western Union, MoneyGram, T/T, D/P
Supply Ability 100000pcs Per Day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Voltage 48V Model 20Ah LiFePO4 Battery Packs
Impedance <500mΩ Cell Type 18650 Battery Cells
Diameter 29.5*9*7.3cm Capacity 20Ah 960Wh
Cycle Life >5000 Cycles Standard Charge Current Constant Current 0.2C
Certifications CE /UL/UN38.3/ MSDS Standard Discharge Current Constant Current 0.2C
High Light

UN38.3 48V 20AH Lithium Battery


960Wh 48v 20ah Lithium Ion Battery


MSDS 18650 LiFePO4 Battery Cell

Leave a Message
Product Description

18650 48V 20AH Lithium Battery For Motor Electric Bicycle Bike Scooter


48V 20AH Lithium LiFePO4 Battery For 750W 1000W 1200W Motor Electric Bicycle Bike , Scooter Golf Cart


48V 20AH Lithium Battery Quick details :


1. Diameter*Height : 300 * 90 * 80mm (Lithium LiFePO4 18650 13S8P )

2. Nominal Voltage : 48V

3. Nominal Capacity : 20Ah 960Wh

4. Cycle life : 5000 cycles

5. Standard charging ways : CC / CV

6. Li-ion / Lithium Ion rechargeable LiFePO4 battery cell

7. CE , UL ,UN38.3 , MSDS compliant


LiFePO4 Battery Cell Description :


48 Volt 20Ah lithium battery pack, fit for 100W to 1200W ebikes/motor/scooter. 13S8P 104PCS batteries cells Fully Capacity. Original Charger: 42V 2A with cooling fan


Battery equipped with 35A BMS protective board prevent short circuit, over charge and over discharge ensure the above 1500 cycling long life expectancy.


lithium iron batteries have exceptional quality since they are manufactured by Automotive Grade LiFePO4 Cells with higher energy density, more stable performance & greater power. Highest-level safety based on UL Testing Certificate for the cell inside the battery. With no acid in the battery, you're able to safely mount in any position. This makes li-iron batteries perfect for solar home, RV, campers, golf cart, motor homes, off-grid applications.


LiFePO4 battery provides 4000~8000 cycles, which is more than 10 times to Lead Acid with 200~500 cycles. Ampere Time LiFePO4 battery has a 10-year service life, three times longer than the Lead Acid’s 3-year .


LiFePO4 Battery weighs only 47.4 lbs for one module, only 1/3 the weight of lead acid batteries, which makes it an easy choice for RVs, Marine and Off-Grid Applications when mounting or mobility is in the consideration.


LiFePO4 battery has built-in BMS to protect it from overcharge, over-discharge, overcurrent, and short circuit with excellent self-discharge rate. Operating Temp: Charge: 0°C~50°C; Discharge: -20°C~60°C. Our battery is IP65 waterproof, setting you free from worrying to install indoors or outdoors.


We can also customize any size and function you need.Such as 12V/24V/36v/48v/60V/72v 20AH, 50AH,100h, 120ah, 150ah,200ah, 300ah, 400ah, 800ah etc..


Lithium LiFePO4 Battery Specifications :


NO Items Specification Remarks
1 Nominal Capacity 20Ah 0.2C  Discharge
0.2C  Discharge
2 Nominal Voltage/shipping voltage 48V Voltage
3 Discharge Cut-off Voltage 50V 0.2C Discharge
0.2C Discharge
4 Charge Limited Voltage 48V 0℃~45℃
5 Standard Charge Current 4A 0℃~45℃
6 Standard Discharge Current 4A -20℃~ +60℃
7 Rapid Charge Current 0.5C 4A 10℃~45℃
8 Rapid Discharge Current 0.5C 4A -20℃~ +60℃
9 Max. Charge Current 1C 20A
Max Pulse Current 3C
10 Internal Impedance ≤100mΩ AC 1kHz condition
At AC 1kHz
11 Weight About 5kg Weight 5kg
12 Storage Temperature Range ≤1 month -20~ 45℃ Factory Voltage 48~50V
≤3 months 0℃~ +30℃ Ex-factory Voltage 48~50V
≤12 months 20±5℃



Lithium LiFePO4 Battery Products Details :


18650 48V 20AH Lithium Battery For Motor Electric Bicycle Bike Scooter 018650 48V 20AH Lithium Battery For Motor Electric Bicycle Bike Scooter 1



Lithium LiFePO4 Battery Applications :


Can be connected in series (up to 2).Perfect for power station camping, marine, RV, campers, golf cart, medical devices, motorhomes & electric mobility scooter, off-road and off-grid applications!

18650 48V 20AH Lithium Battery For Motor Electric Bicycle Bike Scooter 2
